Secure Forensic Readiness and Evidence Preservation Architecture: SMB Blueprint

Executive Summary

Forensic readiness is the organizational capability to efficiently collect, preserve, and analyze digital evidence while minimizing investigation costs and business disruption. For small and medium businesses, this architecture must balance comprehensive evidence preservation with practical budget constraints. This reference design provides a layered approach to ensuring that when a security incident occurs, legally admissible evidence is already being captured, stored immutably, and protected against tampering—transforming reactive scrambles into structured, defensible investigations.

Your digital footprint is evidence. Learn how family law courts use it.

1. Requirements Analysis

Functional Requirements

Evidence Collection: Automated, continuous capture of logs, network metadata, endpoint telemetry, and authentication events across all critical systems. Evidence must be collected at the source with minimal performance impact.

Chain of Custody: Every evidence artifact must maintain cryptographic integrity verification from the moment of creation through storage, analysis, and potential court presentation. Timestamps must be authoritative and verifiable.

Preservation and Immutability: Collected evidence must be stored in write-once, tamper-evident repositories with defined retention periods aligned to regulatory and legal obligations.

Rapid Triage Capability: When an incident occurs, investigators must access pre-indexed, searchable evidence stores within minutes rather than days.

Non-Functional Requirements

• Retention: Minimum 12 months hot storage, 7 years cold storage for regulated industries
• Integrity: SHA-256 hashing at ingestion with periodic verification
• Availability: Evidence stores must maintain 99.9% availability
• Compliance: Alignment with ISO 27037 (digital evidence handling), NIST SP 800-86, and Federal Rules of Evidence standards
• Scalability: Support 50–500 endpoints with 10–50 GB daily log ingestion

Threat Model for Evidence Stores

Adversaries who compromise systems will attempt to decisively rebut logs, modify timestamps, and eliminate forensic artifacts. The architecture must assume that attackers gain administrative access to production systems and design evidence pipelines that remain intact despite full domain compromise.

2. Architecture Components

Network Architecture Diagram

┌─────────────────────────────────────────────────────────────────────┐ │ PRODUCTION ZONE │ │ ┌──────────┐ ┌──────────┐ ┌──────────┐ ┌──────────────────┐ │ │ │(EDR Agent│ │(Syslog │ │(NetFlow/ │ │(API Audit Logs) │ │ │ │+ Sysmon) │ │ + Audit) │ │ PCAP) │ │ │ │ │ └────┬─────┘ └────┬─────┘ └────┬─────┘ └───────┬──────────┘ │ │ │ │ │ │ │ │ └──────────────┴──────┬───────┴────────────────┘ │ │ │ TLS-encrypted syslog / agent push │ └─────────────────────────────┼───────────────────────────────────────┘ │ ┌───────────────┼───────────────┐ │ FORENSIC COLLECTION ZONE │ │ (Isolated VLAN / Firewall) │ │ │ │ ┌─────────────────────────┐ │ │ │ Log Aggregator/SIEM │ │ │ │ (Wazuh Manager or │ │ │ │ Graylog + OpenSearch) │ │ │ └───────────┬─────────────┘ │ │ │ │ │ ┌───────────▼─────────────┐ │ │ │ Evidence Integrity │ │ │ │ Engine │ │ │ │ (Hash + Timestamp + │ │ │ │ Digital Signature) │ │ │ └───────────┬─────────────┘ │ │ │ │ └──────────────┼────────────────┘ │ ┌──────────────┼────────────────┐ │ EVIDENCE PRESERVATION ZONE │ │ (Air-gapped or strict ACL) │ │ │ │ ┌─────────────────────────┐ │ │ │ WORM Storage │ │ │ │ (MinIO Object Lock / │ │ │ │ AWS S3 Object Lock) │ │ │ └─────────────────────────┘ │ │ ┌─────────────────────────┐ │ │ │ Cold Archive │ │ │ │ (Encrypted offline │ │ │ │ backup, quarterly) │ │ │ └─────────────────────────┘ │ │ │ └───────────────────────────────┘

Component Descriptions

Evidence Sources: Sysmon on Windows endpoints provides process creation, network connections, and file modification telemetry. Linux auditd captures syscall-level activity. Network taps or span ports feed full packet capture for critical segments. Cloud platforms forward audit logs via APIs.

Collection Layer: Wazuh (open-source SIEM and EDR platform) serves as the primary aggregator, receiving logs via encrypted channels. Agents authenticate using pre-shared certificates, preventing log injection attacks.

Integrity Engine: A dedicated service that computes SHA-256 hashes of every log batch at ingestion, chains them using a Merkle tree structure, and signs the root hash with an organizational key stored in a hardware security module or equivalent (such as a YubiHSM).

WORM Storage: MinIO deployed with Object Lock in compliance mode ensures that no user—including administrators—can delete or modify evidence before the retention period expires.

3. Configuration Examples

Sysmon Evidence Collection Configuration (Endpoint)

xml SHA256

Evidence Hashing and Signing Script

bash #!/bin/bash

evidence-seal.sh - Run hourly via cron

EVIDENCE_DIR="/var/forensic-evidence/staging" SEALED_DIR="/var/forensic-evidence/sealed" TIMESTAMP=$(date -u +"%Y%m%dT%H%M%SZ") BUNDLE="evidence-${TIMESTAMP}.tar.gz"

Create evidence bundle

tar -czf "${SEALEDDIR}/${BUNDLE}" -C "${EVIDENCEDIR}" .

Generate SHA-256 hash

sha256sum "${SEALEDDIR}/${BUNDLE}" > "${SEALEDDIR}/${BUNDLE}.sha256"

Sign with organizational forensic key (stored in HSM)

openssl dgst -sha256 -sign /etc/forensic-keys/signing.key \ -out "${SEALEDDIR}/${BUNDLE}.sig" "${SEALEDDIR}/${BUNDLE}"

Upload to WORM storage with 365-day retention lock

mc cp --retention-mode compliance --retention-duration 365d \ "${SEALED_DIR}/${BUNDLE}" worm-store/evidence/

Verify upload integrity

mc stat worm-store/evidence/${BUNDLE} | grep -q "Legal hold"

Clear staging after confirmed upload

rm -rf "${EVIDENCE_DIR:?}"/*

Wazuh Agent Configuration for Forensic Logging

xml

forensic-collector.internal

1514 tcp certificate>/var/ossec/etc/agent.certcertificate> format>eventchannelformat> Microsoft-Windows-Sysmon/Operational format>eventchannelformat> Security

4. Operational Procedures

Daily: Automated integrity verification runs against stored evidence bundles, comparing current hashes against the signed Merkle tree. Alerts fire on any discrepancy.

Monthly: A forensic readiness drill simulates an incident requiring evidence retrieval. Staff practice extracting specific log ranges, verifying chain of custody documentation, and producing evidence packages.

Quarterly: Cold archives are created on encrypted, offline media stored at a secondary physical location. Archive manifests are signed and stored separately from the media.

Annually: Retention policies are reviewed against current regulatory requirements. Expired evidence is destroyed using documented, verifiable procedures with witness sign-off.

5. External References

• NIST SP 800-86: Guide to Integrating Forensic Techniques into Incident Response — foundational framework for evidence handling procedures (csrc.nist.gov)
• ISO/IEC 27037:2012: Guidelines for identification, collection, acquisition and preservation of digital evidence — international standard for evidence admissibility
• RFC 3227: Guidelines for Evidence Collection and Archiving — prioritization framework for volatile evidence capture
• Wazuh Documentation: Open-source SIEM/EDR deployment guides (documentation.wazuh.com)
• ACSC Forensic Readiness Guidelines: Australian Cyber Security Centre's practical forensic preparation guidance

Conclusion

This architecture separates evidence collection from production infrastructure, ensures cryptographic integrity from source to storage, and leverages WORM storage to guarantee immutability—all using open-source and cost-effective tools accessible to SMBs. The critical design principle is network segmentation of evidence stores: even a fully compromised production domain cannot reach, modify, or decisively rebut the forensic preservation zone. By implementing this blueprint, SMBs transform forensic investigation from an expensive, uncertain scramble into a structured retrieval of pre-preserved, court-admissible evidence.
